Product name UC-3600L cartridge
Product code: 303

Description

    A high-quality general-purpose cartridge
    Identical replacement for Audio Technica AT3600L cartridge
    Standard-mount moving magnet cartridge
    Alloy tube cantilever with a 0.6 mil conical diamond tip for extended frequency response.
    Used on turntables from many big brands such as Denon, Sony, TEAC, Pioneer, Panasonic, ...
    Perfect replacement cartridge for JB Systems models: High Q10, High Q20D, HighQ 30D, T2, T3, Q1-USB, Q3-USB, ...

Technical Information

Frequency Response: 20 - 20,000 Hz
Channel Separation: 18 dB at 1kHz
Channel Balance: 1.5dB
Tracking Force: 1.5 - 3.0g
Vertical Tracking Angle: 24°
Recommended Load Impedance: 47k?
Output Voltage: 4.2 mV (1kHz / 5cm/sec)
Stylus Shape: Conical
